Recommended Multi-Camera Live Streaming System Diagram

This is my recommended system for live streaming with a multi-camera system.  (*click image to see it full size.  Numbers on diagram correspond to equipment list below.)













C – Multi-Camera System
1. Computer: HP Elite Desk i7 Processor, 16GB RAM.
2. Video Interface: AJA U-tap SDI
3. HDMI Camera: Canon R800($200)Canon G40($1,000)
4. HDMI-mini to HDMI cable
5. HDMI-to-SDI Converter: Blackmagic Microconverter
6. SDI Cables (Choose your lengths)
7. Video Switcher: Blackmagic Designs TVS HD
8. SDI Camera: Canon XF205 ($3,000)
9. Multiview Monitor: Samsung LED 32″
10. Tripod: Good ($250) | Better ($550)  (not pictured in diagram)

Recommended Single Camera Live Streaming System Diagram

This is my recommended system for live streaming from a single camera.  (*click image to see it full size.  Numbers on diagram correspond to the equipment links below.)











A – Single Camera Live Stream
1. Computer: HP Elite Desk i7 Processor, 16GB RAM.
2. Video Interface: AJA U-tap HDMI
3. Camera:Canon R800($200)Canon G40($1,000)Canon XF205 ($3,000)
4. HDMI-mini to HDMI cable
5. Tripod: Good ($250) | Best ($550)  (not pictured in diagram)

B – Single Camera Live Stream (with long cable run)
1. Computer: HP Elite Desk i7 Processor, 16GB RAM.
2. Video Interface: AJA U-tap SDI
3. Camera:Canon R800($200)Canon G40($1,000)Canon XF205 ($3,000)
4. HDMI-mini to HDMI cable
5. HDMI-to-SDI Converter: Blackmagic Microconverter
6. SDI Cable (Choose your length)
7. Tripod: Good ($250) | Best ($550)  (not pictured in diagram)

Schematic for H.264 Pro Recorder streaming to MXLight

Someone asked me a for a schematic, or hook up diagram for this setup, so here it is.  Please note the H.264 Pro Recorder only streams with MXLight software (or livestream Producer program, which is a paid service.)  and it is NOT the solution I recommend for live streaming.  It DOES NOT work with OBS or other streaming encoders.  (Click the photo to see it full size.)

The H.264 Pro Recorder does work well for recording your video on to a computer through the BMD Media Express software.











A – Canon Vixia R800
B – H.264 Pro Recorder
C – ART CleanBoxPro
D – XLR to 1/8″
E – Mini-HDMI to HDMI cable
F – USB Mini-B cable
